Halogen Moisture Meter

Product ID: VM-01S

Introduction

Halogen Moisture Analyzer works for the injection of iodine or bromine and other halogen gas in the bulb, at high temperature, the sublimation of tungsten and halogen chemical action, sublimation of tungsten on tungsten will re-solidify to form a balanced cycle, to avoid premature rupture of tungsten. Therefore, live longer than incandescent halogen bulbs. And because the filament can work at higher temperatures, resulting in a higher brightness, higher color temperature and higher luminous efficiency.

Moisture Analyzer distinguish it from other products in that moisture traditional oven drying method is generally used to test a sample of three or even take two or three or four hours and needs by weighing scales, manual calculation, in order to obtain Moisture value (water content) of the sample. Low efficiency of traditional oven method of moisture determination, not able to adapt to the fast pace of production needs. VM-01S high efficiency of the drying heater - high quality ring halogen, samples are quick and uniform heating, water samples continued to be dried. The entire measurement process, rapid moisture analyzer fully automated real-time display of measurement results: Sample weight, moisture content, solids, measurement time, the heating temperature.

Halogen Moisture Analyzer application of the international principle oven drying, moisture determination with the oven method of measurement of a good consistency, efficiency is much higher than the moisture determination oven method. Use VM-01S Halogen Moisture Analyzer, general sample measurement is completed only a few minutes, so by the business users love and praise.



Features

1.No need to install & commissioning

2.Easy Operation and no need use training

3.Short test time and high efficiency

4.Heating uniformity, stable performance, high accuracy

5.Small size and light weight

6.Automatic measurement, End buzzer, without care when working

7.Versatile, suitable for almost all sectors of moisture determination

8.High performance electromagnetic force sensor, the maximal capacity can reach 0.1mg readability, provide the best measured performance.

9.Unique windscreen design, makes the weighing system more stable

10.Show the moisture (water content) & Solid content at the same time

11.Pure stainless-steel heating chamber cavity cover, high temperature, easy to clean.



Specifications

Model

VM-01S

Max. Weight

120g

Weighing Readability

0.0001g-120g

Repeatability (Standard Error)

±0.001%

Operational Temperature Range

13-25 Best

Calibration Method

External weights calibration

Tray Diameter

Φ90mm

Preheat Time

20-30 minutes

Baud Rate Options

3006001200240048009600

Display Screen

LCD (Liquid Crystal Display)

Temperature Sensor

High Precision PT100 platinum RTD

Powder

220v±10% 50HZ±1HZ (Customizable)

Heating Temperature Range

60-200

Drying Mode

Standard heating, Step heating, Weight-lost   heating

Moisture Display Mode

Relative Moisture

Stop Mode

Automatic stop, Manual stop, Timing stop

Time Setting

0~99 minutes, interval 1 minute

Dimensions

310mm×205mm×200mm

Net Weight

5.0 kg
